Gable Roof Shed
Stratco
SKU: Gable-Roof-Shed
Form and function come together in the classic shape of the Gable Roof Shed. Featuring an extremely practical pitched roof, the Stratco Gable Roof Garage and garaport range takes full advantage of the floor space available. Perfect for all your outdoor storage needs. Your shed/garage will be custom designed and made to suit your exact requirements. Whether you want to build it yourself or have it installed, we are here to help. Contact us for pricing and further details today.Image gallery
Gable Garages and Storage Sheds
Strong and practical storage sheds with a timeless 15° gable roof design.
Strong, high quality, practical sheds and garaports that feature a classic 15° gable roof design. A pitched garage roof is more than just attractive, the gable design minimises heat build-up, increases storage space on the inside, and delivers the benefits of a self-cleaning shape on the outside.
Note: Standard double sided colours are displayed below, however the complete range of single sided roofing colours are available upon request. Contact Stratco for more information.
Available Colours:
Brochures & Installation Guides
Quality Garages Built for Strength
The frame of a Gable Roof Shed is constructed using strong, galvanised C-section beams. Hi-tensile bolted eaves and ridge connection brackets provide a seamless portal frame and are engineered to provide additional torsional strength.
Corrugated double sided colour steel is used to clad the shed roof and gutters and downpipes are supplied standard. The sheds double sided colour walls feature Superdek® sheeting, a durable and hard-wearing sheet due to the 28mm high ribs in its profile, or 16mm high corrugated sheeting for a more traditional look.
Shed Sizes
Domestic garages feature 19 sizes, based on two single size widths and three double size widths. The range starts with a smaller storage shed called the Stubbie Shed. Large Rural and Industrial Sheds are also available, click here for more information.
- The Stubbie has a height of 2400mm.
- All other garages are available in heights of 2400mm, 2700mm, 3000mm.
- Custom heights up to 3000mm high are available.
Specifications | ||||||
Size | Name | Width (mm) | Lengths (mm) | |||
---|---|---|---|---|---|---|
Single | Stubbie | 3160 | 3160 | - | - | - |
Gem | 3160 | 6210 | 7730 | 9260 | - | |
Compact | 3920 | 6210 | 7730 | 9260 | - | |
Double | Family | 5450 | 6210 | 7730 | 9260 | 12300 |
Deluxe | 6210 | 6210 | 7730 | 9260 | 12300 | |
Jumbo | 6970 | 6210 | 7730 | 9260 | 12300 |
Note: Sizes shown are based on standard sheet coverages and are variable if required
Options in the Gable Shed Range
Gable Roof Sheds are available in a wide range of colours. Select either sliding garage doors or roller doors. If the side of the storage shed is to be built on a boundary, internal box gutters can be ordered. Optional extras include windows, skylights and single or double personal access doors, insulation and ventilation. Roller doors can be fitted with remote controlled door openers.
- Attached Patios
- Garaports
- Insulated Cooldek® roof panels
- Internal box gutters
- Remote controlled roller door openers
- Single or double personal access doors
- Skylights
- Spinning ventilators
- Wall ventilation louvres
- Louvre or sliding windows
- Roof and wall insulation
- Safety mesh
Engineered For Structural Integrity
Gable Roof Sheds have been independently assessed to meet all relevant Australian Building Standards. This gives you the confidence that a Stratco Garage will stand the test of time. Gable Roof Sheds are designed to suit wind speed areas N1 (W28), N2 (W33) and N3 (W41).
Complete Your Shed With Garage Matting
Install Your Gable Roof Garage
With easy to follow installation instructions and featuring pre-punched and pre-cut framework and steel sheets for a simple construction, 15° Gable Roof Domestic Sheds are the ideal do-it-yourself project. Stratco can also provide a list of qualified garage installers to complete the job for you.
15 Deg Domestic Frame Install
Type 2 | 2x Roller Doors in Gable End
Type 9 | 1x Roller Door in Gutter Side
15 Deg Gable Roof Shed Install Time Lapse
Gable Shed Maintenance
With a simple wash and wipe using a soft broom, your Stratco Gable Garage will maintain its great looks for even longer. Produced from the highest quality materials, you can expect many years of service from your garage if the recommendations in the 'Selection Use and Maintenance Brochure' are followed.
